Piston hydraulique à simple effet et joint de tige. Applications standard simples. Mais pour le joint de piston, MT-P01 est préféré. Comme joint de tige, MT-R01 est préféré.
Application:
Pour vérin hydraulique, pneumatique
Avantage:
Ajustement stable dans le boîtier, excellente performance d’étanchéité. Large plage de température
Matériel:
POLYURÉTHANE, CAOUTCHOUC
| Code MT | DI | DE | B | |
|---|---|---|---|---|
| MT-R06 | 4,0 | 10,0 | 4,0 | |
| MT-R06 | 5,0 | 12,0 | 5,0 | |
| MT-R06 | 6,0 | 12,0 | 4,0 | |
| MT-R06 | 6,0 | 15,0 | 5,0 | |
| MT-R06 | 6,0 | 16,0 | 6,0 | |
| MT-R06 | 7,0 | 15,0 | 5,0 | |
| MT-R06 | 8,0 | 13,0 | 4,0 | |
| MT-R06 | 8,0 | 14,0 | 4,0 | |
| MT-R06 | 8,0 | 14,0 | 4,0 | |
| MT-R06 | 8,0 | 16,0 | 4,0 | |
| MT-R06 | 8,0 | 16,0 | 4,0 | |
| MT-R06 | 8,0 | 12,0 | 4,0 | |
| MT-R06 | 10,0 | 14,0 | 2,0 | |
| MT-R06 | 10,0 | 16,0 | 4,0 | |
| MT-R06 | 10,0 | 18,0 | 5,0 | |
| MT-R06 | 10,0 | 22,0 | 6,0 | |
| MT-R06 | 10,0 | 19,0 | 4,0 | |
| MT-R06 | 10,0 | 20,0 | 4,0 | |
| MT-R06 | 10,0 | 23,0 | 4,0 | |
| MT-R06 | 12,0 | 18,0 | 4,0 | |
| MT-R06 | 12,0 | 20,0 | 6,0 | |
| MT-R06 | 12,0 | 22,0 | 5,0 | |
| MT-R06 | 12,0 | 24,0 | 6,0 | |
| MT-R06 | 12,0 | 23,0 | 4,0 | |
| MT-R06 | 12,0 | 20,0 | 4,0 | |
| MT-R06 | 12,0 | 20,0 | 4,0 | |
| MT-R06 | 14,0 | 20,0 | 4,0 | |
| MT-R06 | 14,0 | 20,0 | 5,0 | |
| MT-R06 | 14,0 | 25,0 | 4,0 | |
| MT-R06 | 15,0 | 22,0 | 4,0 | |
| MT-R06 | 15,0 | 24,0 | 7,0 | |
| MT-R06 | 15,0 | 25,0 | 6,0 | |
| MT-R06 | 16,0 | 22,0 | 4,0 | |
| MT-R06 | 16,0 | 22,0 | 6,0 | |
| MT-R06 | 16,0 | 25,0 | 5,0 | |
| MT-R06 | 16,0 | 26,0 | 5,0 | |
| MT-R06 | 18,0 | 26,0 | 4,0 | |
| MT-R06 | 18,0 | 24,0 | 4,0 | |
| MT-R06 | 18,0 | 25,0 | 4,0 | |
| MT-R06 | 20,0 | 28,0 | 4,0 | |
| MT-R06 | 20,0 | 28,0 | 8,0 | |
| MT-R06 | 20,0 | 30,0 | 8,0 | |
| MT-R06 | 20,0 | 35,0 | 10,0 | |
| MT-R06 | 20,0 | 32,0 | 8,0 | |
| MT-R06 | 22,0 | 30,0 | 6,0 | |
| MT-R06 | 22,0 | 35,0 | 7,0 | |
| MT-R06 | 22,0 | 32,0 | 5,0 | |
| MT-R06 | 22,0 | 28,0 | 5,0 | |
| MT-R06 | 24,0 | 30,0 | 5,0 | |
| MT-R06 | 24,0 | 32,0 | 4,0 | |
| MT-R06 | 24,0 | 34,0 | 5,0 | |
| MT-R06 | 25,0 | 33,0 | 7,0 | |
| MT-R06 | 25,0 | 40,0 | 6,0 | |
| MT-R06 | 27,0 | 36,0 | 6,0 | |
| MT-R06 | 28,0 | 38,0 | 5,0 | |
| MT-R06 | 28,0 | 52,0 | 10,0 | |
| MT-R06 | 29,0 | 35,0 | 6,0 | |
| MT-R06 | 30,0 | 40,0 | 9,0 | |
| MT-R06 | 30,0 | 45,0 | 10,0 | |
| MT-R06 | 30,0 | 55,0 | 12,0 | |
| MT-R06 | 32,0 | 42,0 | 8,0 | |
| MT-R06 | 32,0 | 40,0 | 7,0 | |
| MT-R06 | 32,0 | 48,0 | 8,0 | |
| MT-R06 | 32,0 | 40,0 | 4,0 | |
| MT-R06 | 33,0 | 42,0 | 7,0 | |
| MT-R06 | 35,0 | 45,0 | 5,0 | |
| MT-R06 | 35,0 | 45,0 | 6,0 | |
| MT-R06 | 35,0 | 42,0 | 5,0 | |
| MT-R06 | 40,0 | 50,0 | 5,0 | |
| MT-R06 | 40,0 | 60,0 | 10,0 | |
| MT-R06 | 40,0 | 48,0 | 8,0 | |
| MT-R06 | 46,0 | 70,0 | 12,0 | |
| MT-R06 | 48,0 | 60,0 | 6,0 | |
| MT-R06 | 48,0 | 60,0 | 7,0 | |
| MT-R06 | 50,0 | 80,0 | 15,0 | |
| MT-R06 | 50,0 | 75,0 | 12,0 | |
| MT-R06 | 55,0 | 70,0 | 10,0 | |
| MT-R06 | 58,0 | 70,0 | 6,0 | |
| MT-R06 | 60,0 | 100,0 | 20,0 | |
| MT-R06 | 61,0 | 73,0 | 6,0 | |
| MT-R06 | 62,0 | 86,0 | 12,0 | |
| MT-R06 | 64,0 | 80,0 | 8,0 | |
| MT-R06 | 72,0 | 84,0 | 8,0 | |
| MT-R06 | 72,0 | 84,0 | 6,0 | |
| MT-R06 | 72,0 | 82,0 | 5,0 | |
| MT-R06 | 75,0 | 100,0 | 12,0 | |
| MT-R06 | 75,0 | 90,0 | 8,0 | |
| MT-R06 | 80,0 | 100,0 | 10,0 | |
| MT-R06 | 83,0 | 95,0 | 10,0 | |
| MT-R06 | 130,0 | 150,0 | 10,0 | |
| MT-R06 | 135,0 | 150,0 | 10,0 | |
| MT-R06 | 220,0 | 250,0 | 15,0 | |
| MT-R06 | 230,0 | 270,0 | 20,0 | |
| MT-R06 | 290,0 | 330,0 | 20,0 |
